| Strap Size | Average Strength | Yield | |||||||
| Width | Thickness | High tensile strength (Mpa)/ Elongation | Ft/lb | M/kg | |||||
| Inch | mm | inch | mm | ≥930/≥8% | ≥980/≥12% | ||||
| Newton | LBS | Newton | LBS | ||||||
| (N) | (N) | ||||||||
| 5/8 | 16 | 0.015 | 0.4 | 5952 | 1339 | 6272 | 1411 | 29.6 | 19.9 |
| 0.02 | 0.5 | 7440 | 1674 | 7840 | 1764 | 23.7 | 15,92 | ||
| 0.023 | 0.6 | 8928 | 2009 | 9408 | 2117 | 19.7 | 13.27 | ||
| 3/4 | 19 | 0.02 | 0.5 | 8835 | 1988 | 9310 | 2095 | 20 | 13.41 |
| 0.023 | 0.6 | 10602 | 2385 | 11172 | 2514 | 16.6 | 11.17 | ||
| 0.028 | 0.7 | 12369 | 2783 | 13034 | 2933 | 14.3 | 9.58 | ||
| 0.031 | 0.8 | 14136 | 3181 | 14896 | 3352 | 12.5 | 8.38 | ||
| 0.035 | 0.9 | 15903 | 3578 | 16758 | 3771 | 11.1 | 7.45 | ||
| 0.04 | 1 | 17670 | 3976 | 18620 | 4190 | 10 | 6.7 | ||
| 1 | 25 | 0.023 | 0.6 | 13950 | 3139 | 14700 | 3308 | 12.6 | 8.49 |
| 0.028 | 0.7 | 16275 | 3662 | 17150 | 3859 | 10.8 | 7.28 | ||
| 0.031 | 0.8 | 18600 | 4185 | 19600 | 4410 | 9.5 | 6.37 | ||
| 0.035 | 0.9 | 20925 | 4708 | 22020 | 4955 | 8.4 | 5.66 | ||
| 0.04 | 1 | 23250 | 5231 | 24500 | 5513 | 7.6 | 5.1 | ||
| 1 1/4 | 31.75 | 0.031 | 0.8 | 23622 | 5315 | 25800 | 5811 | 7.5 | 5.02 |
| 0.035 | 0.9 | 26575 | 5980 | 28004 | 6301 | 6.6 | 4.46 | ||
| 0.04 | 1 | 29528 | 6644 | 31115 | 7001 | 6 | 4.01 | ||
| 0.047 | 1.2 | 35433 | 7972 | 37338 | 8401 | 5 | 3.33 | ||
