Physical Properties
| Grade |
Tensile strength Mpa min |
Enlongation% Min |
| 930KD | 930 | 10 |
| 980KD | 980 | 12 |
| 1150KD | 1150 | 8 |
| 1250KD | 1250 | 6 |
size
| Thickness(mm) | width(mm) |
| 0.4 | 16mm |
| 0.5 | 16,19 |
| 0.6 | 16,19 |
| 0.7 | 19 |
| 0.8 | 19,25.4,31.75,62 |
| 0.9 | 19,25.4,31.75,32,40 |
| 1.0 | 19,25.4,31.75,32,40 |
| 1.2 | 31.75,32,40 |
|
Thickness tolerance 0.4-0.6mm +/- 0.02mm 0.7-1.2mm +/- 0.03mm |
width tolerance: 16mm-40mm - 0.10mm |
Finish
Blue tempered + Waxed
Painted + Waxed, such as black, brown, green, etc
Zinc coated + waxed
Coil Dimension
Coil I.D: 200mm, 300mm, 406mm
Coil O.D (max): 1000mm
| Coil winding | Coil face | Coil weight |
| Ribbon wound |
16mm,19mm, 25.4mm,31.75mm, 32mm,40mm |
45-50kgs |
| Oscillated wound | 63.5mm | 50kgs |
| Jumbo wound | 190mm | 200-400kgs |
